Front and rear hydraulicshock absorption
Shock-absorbing effect is good, greatly enhance riding comfort
Vehicle NameERV
Parameters
- Configuration Code(24th edition)
- Loading Capacity2
- Size(Length * Width * Height) 1720*730*1140mm
- Max Speed30km/h
- Input VoltsAC220V (adjustable 110V)
- Distance between axles1100mm
- Distance between wheels600mm
- Minimum Ground Clearance>85 mm
- Minimum Turning Radius≤1.49 m
- Brake Distance(30km/h)≤7.5m
- Slope-Climbing≤6 °
- Battery48V20AH (LEAD-ACID）
- Battery Weight28KG
- Max load
- Weight(excluding battery)77kg
- Mileage47.6km (single person 75kg, 3rd gear) 39.3km (full load 150kg, 3rd gear)
Electronic control parameters
- ContronlSquare wave controller, 48V12T28A
- MotorMid mounted differential motor, 48V25H350W
- Charger48V3A, filled with 6-8 hours
- Lights & SignalsFront headlights/turn signals/tail lights/horn
- AcousticsNothing
- SwitchesElectric door lock/light (dual flashing)/three speed/reverse
- Panel boardLCD instrument panel, phase line instrument panel
- Other functionsForward reverse/anti slip slope/speed limit/soft and hard start
- Windshield wiperNothing
Body and chassis
- SeatsOne person comfortable seat or double person economy seat
- Body & FrameNon load bearing frame
- BodyNothing
- Body/Sealed DoorEquipped with automotive grade pedal leather
- Windshield & Side mirrorsNo windshield, driver's dual rearview mirrors
- Turning SystemTurn the steering wheel
- Front axle & SuspensionΦ 27 hydraulic shock absorber
- Rear axle & SuspensionRear axle flat fork structure spring damping
- Brake systemFront and rear drum brakes
- TyreFront tire 16 * 2.5, rear tire 2.75-10 vacuum tire/front wheel hub 1.85-10, rear wheel hub 2.15-10 aluminum wheel
- Safety BarFront and rear bumpers
Loading
- 20 feet (for small-sized models)Half scattered SKD48 units without battery cardboard box. 95 sets of fully dispersed CKD are expected to be verified.
- 40 cabinetsHalf scattered SKD96 units do not include battery cardboard boxes. Complete CKD 200 sets.
Others
- OthersCan be equipped with a carport
- Color profileTransparent Red Maroon tm, Honda Grey, Dreamy Orange
